Wingless and Archipelago, a fly E3 ubiquitin ligase and a homolog of human tumor suppressor FBW7, show an antagonistic relationship in wing development

BMC Developmental Biology volume 20, Article number: 14 (2020) Cite this article

Abstract

Background

Archipelago (Ago) is a Drosophila homolog of mammalian F-box and WD repeat domain-containing 7 (FBW7, also known as FBXW7). In previous studies, FBW7 has been addressed as a tumor suppressor mediating ubiquitin-dependent proteolysis of several oncogenic proteins. Ubiquitination is a type of protein modification that directs protein for degradation as well as sorting. The level of beta-catenin (β-cat), an intracellular signal transducer in Wnt signaling pathway, is reduced upon overexpression of FBW7 in human cancer cell lines. Loss of function mutations in FBW7 and overactive Wnt signaling have been reported to be responsible for human cancers.

Results

We found that Ago is important for the formation of shafts in chemosensory bristles at wing margin. This loss of shaft phenotype by knockdown of ago was rescued by knockdown of wingless (wg) whereas wing notching phenotype by knockdown of wg was rescued by knockdown of ago, establishing an antagonistic relationship between ago and wg. In line with this finding, knockdown of ago increased the level of Armadillo (Arm), a homolog of β-cat, in Drosophila tissue. Furthermore, knockdown of ago increased the level of Distal-less (Dll) and extracellular Wg in wing discs. In S2 cells, the amount of secreted Wg was increased by knockdown of Ago but decreased by Ago overexpression. Therefore, Ago plays a previously unidentified role in the inhibition of Wg secretion. Ago-overexpressing clones in wing discs exhibited accumulation of Wg in endoplasmic reticulum (ER), suggesting that Ago prevents Wg protein from moving to Golgi from ER.

Conclusions

We concluded that Ago plays dual roles in inhibiting Wg signaling. First, Ago decreases the level of Arm, by which Wg signaling is downregulated in Wg-responding cells. Second, Ago decreases the level of extracellular Wg by inhibiting movement of Wg from ER to Golgi in Wg-producing cells.

Background

Degradation of proteins is a fast and reliable process to eliminate activity of a given protein spatiotemporally for various functions such as cell proliferation, differentiation and survival. Ubiquitination is one of major mechanisms for protein degradation by conjugating ubiquitin to a target protein that acts as a recruiting signal for proteasome complex [1]. In addition, ubiquitin moiety functions in proteasome-independent ways as an internalization signal or as a sorting signal to regulate endocytosis and secretory pathway [2]. Fly Ago is a component of F-box protein in E3 ubiquitin ligase complex, and it recognizes specific substrates such as Myc, Trachealess (Trh), Similar (Sima) and Cyclin E (Cyc E) for ubiquitination [3,4,5,6]. Similarly, human FBW7 as a homolog of Ago has over 60 known substrates such as Cyc E, Myc, Jun, Notch and mTOR [7,8,9,10,11]. FBW7 has been considered as a tumor suppressor and is one of the most frequently mutated genes in human cancers [12].

Wg/Wnt, as one of key signaling proteins, is highly conserved in all animals. It is involved in diverse cellular processes during development as well as adult homeostasis [13, 14]. It has been reported that fly Wg is secreted initially to the apical surface, transcytosed and then secreted to the basolateral surface in wing discs, which is consistent with findings that intracellular Wg is enriched in the apical region of Wg-producing cells but the majority of extracellular Wg is basolaterally enriched [15, 16]. In canonical Wg pathway, Wg binds to cell surface receptor Frizzled (Fz) and co-receptor Arrow (Arr), and their interaction leads to the stabilization of cytoplasmic Arm that moves into the nucleus and functions as a co-transcription factor [17], by which transcription of multiple genes such as distal-less (dll) is induced [18]. Overactivation of Wnt signaling is responsible for human cancers, especially colorectal cancer [19, 20].

Here, we show that Ago decreased the amount of Arm in wing discs, which is consistent with a report that FBW7 downregulates Wnt signaling by reducing the amount of β-cat [21]. Furthermore, knockdown of Ago increased the level of extracellular Wg in both wing discs and S2 cell culture. In contrast, overexpression of Ago decreased the level of secreted Wg in S2 cell culture. In line with this, Wg was accumulated in ER of wing disc cells upon Ago overexpression, suggesting problems in Wg trafficking. Thus, Ago downregulates Wg signaling by reducing the level of extracellular Wg in Wg-producing cells as well as by reducing the level of Arm in Wg-responding cells. Such cumulative effects of Ago on Wg signaling would affect Dll expression, wing size and development of chemosensory bristles.

Results

Ago is involved in wing growth and formation of chemosensory bristles

ago was identified as a modifier of wg in a genetic screen (Nam S., in preparation), which led us to examine the loss of ago phenotypes in the adult wing, a great tool for studying Wg signaling [22]. To modulate the level of Ago in flies, we utilized two UAS-ago lines (myc-ago and agoUAS.ORF) and two UAS-ago RNAi lines (agoHM04005 and agoHMS00111). These two UAS-ago RNAi lines target different regions in the ago gene (Additional file: Fig. S1A). These flies were all obtained from stock centers except for UAS-myc-ago fly that was generated with a pUAS-myc-ago construct in our laboratory (Additional file: Fig. S1B-D). Progeny from crosses between two UAS-ago RNAi lines with same Gal4 lines showed similar phenotypes, indicating that the knockdown phenotype of ago is not due to off-target effects (see below).

Among Gal4 lines tested, the two ago RNAi lines driven by apterous (ap)-Gal4 driver decreased the number of chemosensory bristles to only 43% of wild-type without affecting mechanosensory bristles (Fig. 1a-c and g). Closer examination revealed, however, that shafts of the chemosensory bristles are lost but unusually enlarged sockets are still present (magnified in Fig. 1a'-c'). Unlike knockdown of ago, overexpression of ago by ap-Gal4 reduced the number of both mechano- and chemo-sensory bristles (Fig. 1d-e and g). Expression level of Ago also affected wing size (Fig. 1h and Additional file: Fig. S2). Knockdown of ago by agoHM04005 and agoHMS00111 expression increased wing size by 13 and 17%, respectively, whereas agoUAS.ORF and myc-ago expression decreased wing size by 16 and 2%, respectively (Fig. 1h). Coexpression of ago RNAi and myc-ago significantly rescued both the number of chemosensory bristles and wing size, indicating that reduction in the amount of endogenous Ago by ago RNAi expression is compensated by overexpression of exogenous Myc-Ago (Fig. 1f-h).

Fig. 1
figure 1

ago is necessary for development of chemosensory bristles at wing margin. In all figures, chemosensory bristles with shafts and without shafts are marked with black arrows and red arrowheads, respectively. a-f Phenotypes of chemosensory bristles in control ap-Gal4/+ (n = 32, a), ap > ago RNAi (agoHM04005, agoHMS00111) (n = 26, b, and n = 46, c), ap > ago (agoUAS.ORF, myc-ago) (n = 18, d, and n = 24, e) and ap > agoHMS00111myc-ago (n = 21, f) wings. Images were taken by focusing on sensory bristles at dorsal anterior wing margin. Proximal to the left. Portions of the wings in (a-f) are magnified in (a'-f') and further magnified images in insets are to show chemosensory bristles. g Numbers of mechanosensory and chemosensory bristles along the anterior wing margin from proximal to distal tip of the longitudinal vein 2 were counted, and the data are presented in the bar graph (***p < 0.001 and ****p < 0.0001). The blue and orange bars represent numbers of mechanosensory and chemosensory bristles, respectively. h Whole wing images as shown in Additional file: Fig. S2 were used to calculate wing size (****p < 0.0001)

Full size image

Ago in sense organ cells is important for the formation of shafts in chemosensory bristles

To examine the role of Ago strictly in cells of sense organ lineage, we used neuralized (neur)-Gal4 that drives expression only in sense organ lineage (Fig. 2). Expression of agoHMS00111 (hereafter UAS-ago RNAi) by neur-Gal4 at 25 °C did not change wing size, but decreased the number of chemosensory bristles to 27% of the control without affecting mechanosensory bristles (Fig. 2a-b',d). Overexpression of UAS-myc-ago affected neither wing size nor any sensory bristles (Fig. 2c,c',d). Similar to ap > ago RNAi wings, all defective chemosensory bristles in neur > ago RNAi wings had enlarged sockets without shafts (Fig. 2e). This loss of shaft phenotype was not recapitulated by expression of dMyc or Cyc E, two well-known substrates of Ago, suggesting that this phenotype is not due to accumulation of these Ago substrates (Additional file: Fig. S3). Taken together, changes in Ago level in the entire dorsal domain by ap-Gal4 affected both wing size and sensory bristles but those in sense organ lineage by neur-Gal4 affected only chemosensory bristles.

Fig. 2
figure 2

Knockdown of ago results in loss of shafts in chemosensory bristles. a-c Wings of progeny from a cross between neur-Gal4 and w1118 (n = 24, a) as control, neur > ago RNAi (n = 11, b) and neur > myc-ago wings (n = 13, c). Portions of wings in (a-c) are magnified in (a'-c'). Proximal to the left. d Numbers of mechanosensory and chemosensory bristles of the wings described in (a-c) were counted. The blue and orange bars represent mechanosensory and chemosensory bristles, respectively. (****p < 0.0001). e Sockets with and without shafts in chemosensory bristles were counted and their numbers are presented in a bar graph with orange and grey colors, respectively. (****p < 0.0001). All flies were cultured at 25 °C

Full size image

ago and wg show an antagonistic relationship

Involvement of Ago in wing development prompted us to examine the relationship between ago and wg. We chose C96-Gal4 that drives expression in the dorsal-ventral (DV) margin region of wing discs. We found that all C96 > ago RNAi wings are normal whereas all C96 > wg RNAi wings lack wing margin (n = 15 for each group, Fig. 3a-c). Interestingly, this loss of wing margin phenotype was substantially rescued by coexpression of ago RNAi in all wings examined (n = 16, Fig. 3d). Therefore, an antagonistic relationship exists between ago and wg.

Fig. 3
figure 3

ago and wg show an antagonistic relationship. a-d Loss of wing margin by knockdown of wg is rescued by knockdown of ago. C96-Gal4 was used to drive wg RNAi (b), ago RNAi (c) or together (d) at 25 °C. C96-Gal4/+ wing as a control (a). e Lethal phenotype by knockdown of wg is rescued by knockdown of ago. That is, ci-Gal4/CyO females and w1118, UAS-ago RNAi, UAS-wg RNAi or UAS- wg RNAi ago RNAi males were crossed, and their progeny with ci-Gal4, but not CyO, were counted (n > 50 for each group). Because the control cross between ci-Gal4/CyO females and w1118 males yielded 40% ci-Gal4/+ and 60% +/CyO progeny, expected factor 0.67 (40/60), was considered in calculating survival rates of progeny in experimental groups. *p < 0.05. f-j Loss of shafts in chemosensory bristles by knockdown of ago is rescued by knockdown of wg. neur-Gal4/+ control (n = 19, f), neur > ago RNAi (n = 13, g), neur > ago RNAi wg RNAi (n = 8, h) and neur > wg RNAi (n = 16, i) wings. Quantitative analysis of these bristles is presented in (j) (****p < 0.0001). Flies were cultured at 18 °C

Full size image

We then used ci-Gal4 to further check the relationship between ago and wg. ci-Gal4/CyO flies were crossed with w1118, UAS-ago RNAi, UAS-wg RNAi or UAS- wg RNAi ago RNAi flies and cultured at 18 °C, and their progenies were counted for survival rate. In all cases, flies containing ci-Gal4 but not CyO were calculated (Fig. 3e). As a control, cross between ci-Gal4/CyO and w1118 yielded 40% ci-Gal4/+ and 60% +/CyO progeny. Compared to control ci-Gal4/+ progeny, ci > ago RNAi flies showed 24% higher survival rate whereas ci > wg RNAi flies showed 36% lower survival rate. Consistent with wing margin phenotype described above, the survival rate of ci > wg RNAi flies was increased to control level by coexpression of ago RNAi in ci > wg RNAi ago RNAi flies (Fig. 3e).

In case of chemosensory bristles, 57% of neur > ago RNAi wings had no shafts but only 25% of neur > ago RNAi wg RNAi wings had no shafts at 18 °C, indicating that knockdown of ago phenotype was partially rescued by knockdown of wg (Fig. 3f-j). Taken together, ago and wg have an antagonistic relationship.

Amount of Arm and level of Wg signaling negatively correlate with level of Ago

We then examined the relationship between Ago and Arm, a key transducer of Wg signaling because our results suggested that the loss of ago excessively promotes Wg signaling. When ArmS10, a truncated Arm protein that is constitutively active [23], was expressed by nubbin (nub)-Gal4 at 18 °C, 78% of pupal lethality was observed (Fig. 4a). This ArmS10-driven lethality was slightly increased by coexpression with ago RNAi but significantly suppressed to 45% by coexpression with ago. Consistent with this, the level of endogenous Arm was increased by 19% in hs > ago RNAi but decreased by 11% in hs > myc-ago when level of Arm was compared in cell extracts from hsp70 > GFP, hsp70 > ago RNAi and hsp70 > myc-ago larvae that had been heat-shocked for an hour before sampling (Fig. 4b). Therefore, knockdown of ago increased the amount of Arm, which may enhance Wg signaling.

Fig. 4
figure 4

Knockdown of ago enhances canonical Wg signaling by increasing the level of Arm. a Lethality caused by overexpression of ArmS10 is suppressed by Ago. Only female progeny from crosses between nub-Gal4 females and w1118, UAS-armS10, UAS-armS10UAS-ago RNAi or UAS-armS10UAS-ago males were counted (n > 100 for each group) for survival rate since UAS-ArmS10 transgene is present in the first chromosome. The control cross yielded 45% female and 54% male of nub-Gal4/+. *p < 0.05, **p < 0.01 and ***p < 0.001. b Level of Arm is increased by knockdown of Ago and decreased by overexpression of Ago in cell extracts from larvae expressing GFP, ago RNAi and myc-ago. α-Tubulin as a control. c Knockdown of Ago enhances Wg signaling activity. S2R+ cells were transfected with ago dsRNA or myc-ago, and Wg activity was measured. Results from triplicate experiments are presented (***p < 0.001)

Full size image

To further test the importance of Ago in regulation of Wg signaling, we changed the level of Ago protein by transfecting S2R+ cells with either ago dsRNA or pUAS-myc-ago construct along with WISIR vector. After 2 day-culture, these cells were cultured for 20 h with Wg that had been obtained from the conditioned media of S2 tub-wg cell culture. Finally, activity of Wg signaling was measured by TOP Flash assay with the WISIR vector (Wingless Signaling Reporter) [24]. We found that ago dsRNA-treated cells show 30% higher Wg activity while MYC-Ago-expressing cells show 9% lower Wg activity than control cells (Fig. 4c). These data are consistent with the findings on the negative interaction between ago and wg.

Knockdown of ago increases level of extracellular Wg secreted from Wg-producing cells

We have shown that knockdown of wg by C96-Gal4 is rescued by knockdown of ago (Fig. 3a-d). C96-Gal4 drives expression in cells at the DV midline that includes Wg-producing cells (Additional file: Fig. S4). Thus, we checked whether knockdown of ago induces any changes in Wg-producing cells. To avoid any developmental defects by prolonged knockdown of ago, ago RNAi was expressed only for 24 h using the inducible Gal4-Gal80ts system [25]. When ago RNAi was expressed by ci-Gal4 for 24 h, the level of extracellular Wg was increased especially in the pouch region of the anterior compartment compared to control discs (n = 7, Fig. 5a,b). This increase was not due to the increase by wg transcription since LacZ level by wg-lacZ expression was not increased by the loss of ago (n = 10, Fig. 5c,d). Additionally, the level of Dll in ci > ago RNAi wing discs was increased in the anterior region, consistent with the higher level of extracellular Wg in the pouch region (n = 11, Fig. 5e,f). Therefore, we conclude that knockdown of Ago increases the level of extracellular Wg by the post-transcriptional mechanism.

Fig. 5
figure 5

Knockdown of Ago increases level of extracellular Wg post-transcriptionally.

Yellow lines delimit the anterior and posterior compartments. a-b Knockdown of Ago increases level of extracellular Wg. Larval progeny from crosses between w1118 (a) or UAS-ago RNAi (b) with ci-Gal4; tub-Gal80ts flies were used to obtain wing discs. Knockdown of Ago by ago RNAi was confirmed with anti-Ago antibody. c-d Knockdown of Ago did not change wg-LacZ pattern. ci > GFP/wg-lacZ control (c) and ci > GFP, ago RNAi/wg-lacZ (d) wing discs show no difference in wg-LacZ pattern. e-f The level of Dll is enhanced by knockdown of Ago. Scale bar, 20 μm.

Full size image

If Ago regulates the level of extracellular Wg, knockdown of Ago in the wing pouch might affect the shape of Wg gradient. To test this, the intensity of extracellular Wg was quantitatively measured in ap > ago RNAi wing discs (n = 5, Additional file: Fig. S5). When ago RNAi was transiently expressed for 24 h by ap-Gal4, the gradient of extracellular Wg in the dorsal compartment became less steep than control discs (Additional file: Fig. S5b). This result supports a new role of Ago in regulating the level of extracellular Wg.

Amount of secreted Wg negatively correlates with that of Ago in S2 cells

To further examine the role of Ago in regulating the level of extracellular Wg, we took a biochemical approach with fly S2 cell culture. S2 cells do not express Wg endogenously [26]; therefore, cells were transfected with GFP-wg in combination with either ago dsRNA or myc-ago (Fig. 6a). After 3-day culture, extracellular Wg was obtained by concentrating conditioned media after removal of dead cells and debris by centrifugation. When GFP-Wg and ago dsRNA were co-expressed, we found that the level of secreted Wg detected by anti-GFP antibody or anti-Wg antibody was increased by 33 and 10%, respectively. In contrast, cells co-expressing MYC-Ago and GFP-Wg secreted 20% less GFP-Wg detected by anti-Wg antibody. When using S2 tub-wg cell line that constitutively expresses Wg, Wg was secreted 14% more by ago knockdown and 19% less by myc-ago overexpression (Fig. 6b). These data established that Ago decreases the level of extracellular Wg secreted from Wg-producing cells.

Fig. 6
figure 6

Overexpression of Ago decreases Wg secretion, and loss of Ago increases Wg secretion in vitro.a Amount of Wg in conditioned media is increased by loss of Ago and decreased by gain of Ago in S2 cells. S2 cells are co-transfected with GFP-wg in combination with either ago dsRNA or myc-ago. Extracellular Wg in culture media and intracellular Wg in cell extracts were detected with both anti-GFP and anti-Wg antibodies. α-Tubulin was used as an internal control. b Level of extracellular Wg was decreased by myc-ago expression in S2 tub-wg cells

Full size image

High level of Ago causes accumulation of Wg in ER

To understand how Ago inhibits secretion of Wg, we checked whether the level of Wg is increased in any subcellular compartments such as ER or Golgi of the Ago-expressing cells in the DV midline since this region is marked by high expression level of endogenous Wg. We generated Ago-overexpressing clones and tested with anti-KDEL and anti-GM130 antibodies that visualize ER and Golgi apparatus, respectively. We found that Wg is more frequently co-localized with KDEL than GM130 in large clones encompassing the DV midline (n = 10, Fig. 7). These results suggest that Ago prevents transport of Wg from ER to Golgi. Although further analysis is required to understand the underlying mechanism of Ago in Wg transport, higher level of Wg in ER by Ago is consistent with the lower level of secreted Wg by Ago overexpression in S2 cell culture.

Fig. 7
figure 7

Overexpression of Ago increases the level of Wg in ER. Clones that overexpress Ago were generated in wing discs outlined in yellow. Endogenous intracellular Wg was detected with anti-Wg, and the clones were marked with GFP. Boxed area in (a'') and (b'') are magnified in (a''') and (b'''). a More co-localization of Wg and ER marker KDEL is observed in an Ago-expressing clone than neighboring cells (arrows). b Less co-localization of Wg and Golgi marker GM130 is seen in an Ago-expressing clone than neighboring cells (arrows). Scale bars, 5 μm

Full size image

Discussion

We have shown here that loss of Ago increases the level of Arm in Wg-responding cells, and it also increases the level of extracellular Wg secreted from Wg-producing cells. Therefore, Ago functions in both cell types to additively reduce activity of Wg signaling. These data are consistent with the antagonistic relationship between ago and wg in phenotypic analyses on wings and chemosensory bristles (Fig. 3). Wing notching phenotype by loss of wg was rescued by loss of ago, while lack of shafts in chemosensory bristles by loss of ago was rescued by loss of wg. Similar antagonistic relation between the two genes has been reported in both flies and mammalian cells. Apoptosis in eye imaginal discs of an ago mutant is suppressed by loss of wg, and ubiquitination of Forkhead box protein M1 (FoxM1) by FBW7 is inhibited by Wnt [27, 28]. Taken together, we conclude that Ago decreases activity of Wg signaling by acting in both Wg-producing and Wg-responding cells, and Ago plays a previously unidentified role in sensory organ development.

Sensory organ precursor (SOP) cells asymmetrically divide to form two external cells, socket and shaft, and two inner cells, neuron and sheath [29]. Socket and shaft cells are two daughter cells generated from a pIIa SOP cell during late 3rd instar to pupal stage [30]. Based on the absence of shafts and enlarged sockets by knockdown of ago, we propose that Ago is involved in the specification of shaft and socket (Fig. 2e). It is plausible that Ago is essential for the formation of shafts, and both daughter cells from the pIIa cell become socket cells in loss of ago condition. Involvement of E3 ubiquitin ligases such as Neur, Mindbomb (Mib) and Drosophila inhibitor of apoptosis1 (Diap1) in sensory bristle formation has been previously reported. For instance, Neur and Mib act prior to SOP formation for non-neuronal fate by regulating Notch signaling activity [31]. On the other hand, Diap1 is dynamically expressed in SOP cells and differentiating sensory organ cells during early pupal stage and is specifically degraded in shaft cells in order to regulate shaft cell morphogenesis [32]. It is interesting to note that Ago/FBW7 decreases whereas Mib1 promotes Wnt signaling [33]. Regulation of Wg signaling by these E3 ubiquitin ligases seems to be important for the formation of sensory organs in flies.

The level of Arm was increased by knockdown of Ago but decreased by gain of Ago (Fig. 4b). It has been shown that FoxM1 phosphorylated by Glycogen synthase kinase 3 (GSK3)/Shaggy is ubiquitinated by FBW7 and degraded when Wnt signaling is inactive. As a result, the level of nuclear FoxM1 that recruits β-cat becomes low, and transcription of Wnt effector genes are not induced. The Level of β-cat is increased by loss of Ago in human pancreatic cancer cells but there is no evidence yet that β-cat is a substrate of FBW7. Therefore, it will be interesting to find out if modulation of Arm level by Ago is via Forkhead box subtype O (FoxO) in flies or if Arm is a direct substrate of Ago.

The level of secreted extracellular Wg was increased by knockdown of Ago and decreased by overexpression of Ago in S2 cell culture (Fig. 6). Ago inhibits Wg secretion from producing cells, and Wg seemed to be held in ER in these cells (Fig. 7). Ago may degrade unknown protein(s) that enhances transport of Wg from ER to Golgi. Alternatively, high level of Ago may affect sorting signals important for Wnt transport [34]. For instance, the amount of Fz in the plasma membrane is regulated by internalization through balanced ubiquitination and deubiquitination [35], and LRP6, a mammalian homolog of Arr, cycles between mono-ubiquitination and deubiquitination in ER until proper protein folding is completed before ER exit [36]. Further detailed analysis is required for understanding how Ago plays as a regulator for Wg trafficking and signal transduction.

Conclusions

Our data established that Ago is essential for wing growth and formation of chemosensory bristles. Gain of Ago decreases the level of Arm and knockdown of Ago increases the level of Arm and extracellular Wg in both wing discs and S2 cells. Meanwhile, overexpression of Ago decreases the level of secreted Wg in S2 cell culture, which may be due to accumulation of Wg in ER instead of transport to Golgi. We demonstrated that antagonistic relationship between ago and wg is essential for wing growth and differentiation of chemosensory organs at wing margin.

Methods

Fly strains

Two ago RNAi lines, #31501 and #34802, were obtained from Bloomington Drosophila stock center (BDSC). The targeting regions for BDSC#31501 and #34802 are 2504-2913th and 5538-5558th nucleotide, respectively (Additional file: Fig. S1 a). Two ago overexpression fly lines used are: FlyORF library #F001828 and line generated with pUAS-myc-ago construct from our laboratory. To make pUAS-myc-ago, an ago cDNA clone (Drosophila Genomics Resource Center clone #LD30271) was sequenced and cloned into pUAST-myc.

All Gal4 lines were obtained from BDSC except ci-Gal4 (gift from R. A. Holmgren). wg-LacZ [37], tub-Gal80ts (BDSC#7017), UAS-wg RNAi (NIG#4889R-3), UAS-armS10 (BDSC#4782), UAS-cyc E (BDSC#4781), UAS-dmyc (BDSC#9674), UAS-nuclear lacZ (BDSC#3955) and UAS-GFP (BDSC#1522) lines were also used. All cultures were carried out at either 18 °C or 25 °C. For conditional induction of Gal4, flies with tub-Gal80ts were incubated at 18 °C until induction at 29 °C.

Wing analysis

Adult wings were dissected from 2 to 3 days-old female adults. Wings were immersed in absolute ethanol and then transferred to mounting medium (80% glycerol in 1X PBS) [38]. Treated wings were then mounted on a slide glass with mounting medium. Wing images were obtained using microscopy under bright field with 40X or 100X magnification and used to count bristles.

Statistical analysis was performed to compare different genotypes to a wild-type control within the experimental groups. Image J program was used to measure the size of adult wings. Data are presented with the standard error of mean (SEM) for multiple batches or the standard deviation (SD) for a single batch of experiments. For statistical significance, t-test of Microsoft Excel was used.

Cell culture and transfection

S2 (stock #6), S2R+ (stock #150) and S2-tub-wg (stock #165) were obtained from Drosophila Genomics Resource Center (DGRC). S2 cells were maintained with 10% artificial serum (Sigma-Aldrich) in M3 media (Sigma-Aldrich). S2R+ and S2-tub-wg cells were cultured in M3 + BPYE containing 10% fetal bovine serum (FBS, Hyclone). 125 μg/ml of hygromycin B (Invitrogen) was added to S2 tub-wg culture, and Cellfectin II (Invitrogen) was used for transfection. For induction of pUAS constructs, pActin-Gal4 DNA was co-transfected with either pUAS-myc-ago or pUAS-GFP-wg.

Double stranded RNA (dsRNA) synthesis

Double-stranded RNA to reduce the level of ago mRNA (ago dsRNA) in S2 cells was synthesized in vitro using MEGAscript RNAi Kit (Ambion). The LD30271 cDNA was used as a template for PCR using forward 5′-AGCAGTGAATCCGTGAC and reverse 5′-CCAGCAAGAACTCATCGCTCA primers conjugated downstream of T7 promoter sequences as written in the manufacturer’s instructions. Cells were treated with 35 nM ago dsRNA for 2 to 3 days until harvest.

TOPFlash assay

S2R+ cells were transfected with either pUAS-myc-ago or ago dsRNA in the presence of WISIR (gift from J. P. Vincent). After 2 days, transfected S2R+ cells were treated with exogenous Wg that had been prepared by concentrating S2 tub-wg cultured media with Amicon centrifugal filter. After 20 h incubation, cells were lysed with 1X passive lysis buffer, and LAR II and STOP&Glo reagents were added (Dual Luciferase Reporter Assay System, Promega). Both firefly luciferase (Luc) and Renilla luciferase (Ren) levels were measured three times. The mean of Luc/Ren ratios were plotted in a bar graph. Error bars indicate standard deviation, and p value was assessed for statistical significance.

Immunoblot analysis

Third instar larvae or S2 cells were lysed with lysis buffer and boiled with sample loading buffer at 95 °C for 10 mins [39]. Prepared samples were loaded on 7.5% SDS-PAGE gel, and protein bands in the gel were transferred to nitrocellulose membrane by wet method. Membranes were blocked with 5% dry milk in TBS-T (140 mM NaCl; 3 mM KCl; 25 mM Tris pH 7.4; 0.1% Tween-20) at room temperature (RT) for 1 h. Membranes were sequentially probed in primary antibody and HRP-conjugated secondary antibody solution diluted with 2% dry milk in TBS-T. After washing, membranes were developed with WESTSAVE-Gold reagent (AbFrontier).

Primary antibodies used are: concentrated anti-Wg (mouse, 1:2000, Developmental Studies Hybridoma Bank (DSHB)), anti-GFP (rabbit, 1:10,000, abcam), anti-αTub (mouse, 1:5000, Sigma-Aldrich), anti-MYC (rabbit, 1:5000, abcam) and anti-Ago (guinea pig, 1:5000, gift from K. H. Moberg). Secondary antibodies used are: HRP-conjugated anti-mouse antibody (1:10,000, Jackson Laboratory), HRP-conjugated anti-rabbit antibody (1:10,000, Jackson Laboratory) and HRP-conjugated anti-guinea pig antibody (1:5000, Jackson Laboratory).

Immunohistochemistry

Wing discs were dissected from third instar larvae and stained as described [40, 41]. After fixing, tissues were immersed in blocking solution for 1 h at RT. The tissues were then incubated at 4 °C overnight sequentially in the primary and secondary antibodies diluted in washing buffer. Lastly, tissues were stained with DAPI. Vectashield (Vector Laboratories, USA) was used for mounting tissues. The following primary antibodies were used for staining: anti-Wg (mouse, 1:100, DSHB), anti-MYC (rabbit, 1:500, abcam), anti-LacZ (chicken, 1:100, abcam), anti-Dll (goat, 1:100, Santa Cruz) and anti-Ago (guinea pig, 1:500, gift from K. H. Moberg). Fluorescent images were acquired using Zeiss confocal microscope LSM 710.

Extracellular Wg staining

For extracellular staining of Wg, larvae were dissected and probed as described [26]. After incubation in concentrated anti-Wg (1:100) primary antibody solution, wing discs were fixed with 4% paraformaldehyde in 1X PBS at RT for 1 h. After washing twice with 1X PBS, samples were immersed in blocking solution without detergent for 1 h at RT. Then the samples were incubated with secondary antibody diluted in detergent-free washing buffer at 4 °C overnight. These samples were washed with detergent-free washing buffer, and then permeabilized in blocking solution containing detergent used for conventional staining. The samples were then stained as described above.

Clonal analysis

To generate ago overexpression clones, hsp70-FLP (BDSC#1929) and UAS-agoUAS.ORF (FlyORF#F001828) were recombined, and hsp70-FLP UAS-ago flies were generated. These flies were crossed with Ay-Gal4,UAS-GFP/CyO (BDSC#4411) and cultured at 18 °C for 5–6 days. Larvae were then shifted to 37 °C for an hour, moved to RT and cultured for 4–5 days. Third instar larvae were then selected and stained by following the conventional staining method described above. The following antibodies were used: Anti-Wg (mouse, 1:100, DSHB), anti-KDEL (rabbit, 1:200, abcam) and anti-GM130 (rabbit, 1:200, abcam).

Availability of data and materials

The datasets used or analysed during the current study are available from the corresponding author on reasonable request.

Abbreviations

Ago:

Archipelago

FBW7:

F-box and WD repeat domain-containing 7

β-Cat:

beta-catenin

Wg:

Wingless

Arm:

Armadillo

Dll:

Distal-less

ER:

Endoplasmic reticulum

Trh:

Trachealess

Sima:

Similar

Cyc E:

Cyclin E

Fz:

Frizzled

Arr:

Arrow

ap :

apterous

neur :

neralized

DV:

dorsal-ventral

nub :

nubbin

WISIR:

Wingless signaling reporter

FoxM1:

Forkhead box protein M1

SOP:

Sensory organ precursor

Mib:

Mindbomb

Diap1:

Death-associated inhibitor of apoptosis1

GSK3:

Glycogen synthase kinase3

FoxO:

Forkhead box subtype O

LRP6:

Low-density lipoprotein (LDL)-related protein 6

References

  1. Clague MJ, Urbe S. Ubiquitin: same molecule, different degradation pathways. Cell. 2010;143(5):682–5.

    Article  CAS  PubMed  Google Scholar

  2. Clague MJ, Urbe S. Integration of cellular ubiquitin and membrane traffic systems: focus on deubiquitylases. FEBS J. 2017;284(12):1753–66.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  3. Moberg KH, Bell DW, Wahrer DC, Haber DA, Hariharan IK. Archipelago regulates Cyclin E levels in Drosophila and is mutated in human cancer cell lines. Nature. 2001;413(6853):311–6.

    Article  CAS  PubMed  Google Scholar

  4. Moberg KH, Mukherjee A, Veraksa A, Artavanis-Tsakonas S, Hariharan IK. The Drosophila F box protein archipelago regulates dMyc protein levels in vivo. Curr Biol. 2004;14(11):965–74.

    Article  CAS  PubMed  Google Scholar

  5. Mortimer NT, Moberg KH. The Drosophila F-box protein archipelago controls levels of the Trachealess transcription factor in the embryonic tracheal system. Dev Biol. 2007;312(2):560–71.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  6. Mortimer NT, Moberg KH. The archipelago ubiquitin ligase subunit acts in target tissue to restrict tracheal terminal cell branching and hypoxic-induced gene expression. PLoS Genet. 2013;9(2):e1003314.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  7. Koepp DM, Schaefer LK, Ye X, Keyomarsi K, Chu C, Harper JW, Elledge SJ. Phosphorylation-dependent ubiquitination of cyclin E by the SCFFbw7 ubiquitin ligase. Science. 2001;294(5540):173–7.

    Article  CAS  PubMed  Google Scholar

  8. Oberg C, Li J, Pauley A, Wolf E, Gurney M, Lendahl U. The notch intracellular domain is ubiquitinated and negatively regulated by the mammalian Sel-10 homolog. J Biol Chem. 2001;276(38):35847–53.

    Article  CAS  PubMed  Google Scholar

  9. Nateri AS, Riera-Sans L, Da Costa C, Behrens A. The ubiquitin ligase SCFFbw7 antagonizes apoptotic JNK signaling. Science. 2004;303(5662):1374–8.

    Article  CAS  PubMed  Google Scholar

  10. Yada M, Hatakeyama S, Kamura T, Nishiyama M, Tsunematsu R, Imaki H, Ishida N, Okumura F, Nakayama K, Nakayama KI. Phosphorylation-dependent degradation of c-Myc is mediated by the F-box protein Fbw7. EMBO J. 2004;23(10):2116–25.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  11. Shimizu K, Nihira NT, Inuzuka H, Wei W. Physiological functions of FBW7 in cancer and metabolism. Cell Signal. 2018;46:15–22.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  12. Cao J, Ge MH, Ling ZQ. Fbxw7 tumor suppressor: a vital regulator contributes to human tumorigenesis. Medicine (Baltimore). 2016;95(7):e2496.

    Article  CAS  Google Scholar

  13. Logan CY, Nusse R. The Wnt signaling pathway in development and disease. Annu Rev Cell Dev Biol. 2004;20:781–810.

    Article  CAS  PubMed  Google Scholar

  14. Clevers H, Nusse R. Wnt/beta-catenin signaling and disease. Cell. 2012;149(6):1192–205.

    Article  CAS  PubMed  Google Scholar

  15. Strigini M, Cohen SM. Wingless gradient formation in the Drosophila wing. Curr Biol. 2000;10(6):293–300.

    Article  CAS  PubMed  Google Scholar

  16. Yamazaki Y, Palmer L, Alexandre C, Kakugawa S, Beckett K, Gaugue I, Palmer RH, Vincent JP. Godzilla-dependent transcytosis promotes wingless signalling in Drosophila wing imaginal discs. Nat Cell Biol. 2016;18(4):451–7.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  17. Clevers H. Wnt/beta-catenin signaling in development and disease. Cell. 2006;127(3):469–80.

    Article  CAS  PubMed  Google Scholar

  18. Swarup S, Verheyen EM. Wnt/Wingless signaling in Drosophila. Cold Spring Harb Perspect Biol. 2012;4:a007930.

    Article  PubMed  PubMed Central  CAS  Google Scholar

  19. Duchartre Y, Kim YM, Kahn M. The Wnt signaling pathway in cancer. Crit Rev Oncol Hematol. 2016;99:141–9.

    Article  PubMed  Google Scholar

  20. Zhan T, Rindtorff N, Boutros M. Wnt signaling in cancer. Oncogene. 2017;36(11):1461–73.

    Article  CAS  PubMed  Google Scholar

  21. Jiang JX, Sun CY, Tian S, Yu C, Chen MY, Zhang H. Tumor suppressor Fbxw7 antagonizes WNT signaling by targeting beta-catenin for degradation in pancreatic cancer. Tumour Biol. 2016;37(10):13893-902.

    Article  CAS  PubMed  Google Scholar

  22. Couso JP, Bishop SA, Martinez Arias A. The wingless signalling pathway and the patterning of the wing margin in Drosophila. Development. 1994;120(3):621–36.

    CAS  PubMed  Google Scholar

  23. Pai LM, Orsulic S, Bejsovec A, Peifer M. Negative regulation of Armadillo, a wingless effector in Drosophila. Development. 1997;124(11):2255–66.

    CAS  PubMed  Google Scholar

  24. Gagliardi M, Hernandez A, McGough IJ, Vincent JP. Inhibitors of endocytosis prevent Wnt/wingless signalling by reducing the level of basal beta-catenin/Armadillo. J Cell Sci. 2014;127(Pt 22):4918–26.

    Article  PubMed  PubMed Central  CAS  Google Scholar

  25. McGuire SE, Le PT, Osborn AJ, Matsumoto K, Davis RL. Spatiotemporal rescue of memory dysfunction in Drosophila. Science. 2003;302(5651):1765–8.

    Article  CAS  PubMed  Google Scholar

  26. Beckett K, Monier S, Palmer L, Alexandre C, Green H, Bonneil E, Raposo G, Thibault P, Le Borgne R, Vincent JP. Drosophila S2 cells secrete wingless on exosome-like vesicles but the wingless gradient forms independently of exosomes. Traffic. 2013;14(1):82–96.

    Article  CAS  PubMed  Google Scholar

  27. Nicholson SC, Gilbert MM, Nicolay BN, Frolov MV, Moberg KH. The archipelago tumor suppressor gene limits rb/e2f-regulated apoptosis in developing Drosophila tissues. Curr Biol. 2009;19(18):1503–10.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  28. Chen Y, Li Y, Xue J, Gong A, Yu G, Zhou A, Lin K, Zhang S, Zhang N, Gottardi CJ, et al. Wnt-induced deubiquitination FoxM1 ensures nucleus beta-catenin transactivation. EMBO J. 2016;35(6):668–84.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  29. Schweisguth F. Asymmetric cell division in the Drosophila bristle lineage: from the polarization of sensory organ precursor cells to notch-mediated binary fate decision. Wiley Interdiscip Rev Dev Biol. 2015;4(3):299–309.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  30. Posakony JW. Nature versus nurture: asymmetric cell divisions in Drosophila bristle development. Cell. 1994;76(3):415–8.

    Article  CAS  PubMed  Google Scholar

  31. Wang W, Struhl G. Distinct roles for mind bomb, Neuralized and Epsin in mediating DSL endocytosis and signaling in Drosophila. Development. 2005;132(12):2883–94.

    Article  CAS  PubMed  Google Scholar

  32. Koto A, Kuranaga E, Miura M. Temporal regulation of Drosophila IAP1 determines caspase functions in sensory organ development. J Cell Biol. 2009;187(2):219–31.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  33. Berndt JD, Aoyagi A, Yang P, Anastas JN, Tang L, Moon RT. Mindbomb 1, an E3 ubiquitin ligase, forms a complex with RYK to activate Wnt/beta-catenin signaling. J Cell Biol. 2011;194(5):737–50.

    Article  PubMed  PubMed Central  Google Scholar

  34. Komander D. The emerging complexity of protein ubiquitination. Biochem Soc Trans. 2009;37(Pt 5):937–53.

    Article  CAS  PubMed  Google Scholar

  35. Mukai A, Yamamoto-Hino M, Awano W, Watanabe W, Komada M, Goto S. Balanced ubiquitylation and deubiquitylation of frizzled regulate cellular responsiveness to Wg/Wnt. EMBO J. 2010;29(13):2114–25.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  36. Abrami L, Kunz B, Iacovache I, van der Goot FG. Palmitoylation and ubiquitination regulate exit of the Wnt signaling protein LRP6 from the endoplasmic reticulum. Proc Natl Acad Sci U S A. 2008;105(14):5384–9.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  37. Kassis JA, Noll E, VanSickle EP, Odenwald WF, Perrimon N. Altering the insertional specificity of a Drosophila transposable element. Proc Natl Acad Sci U S A. 1992;89(5):1919–23.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  38. Dar AC, Das TK, Shokat KM, Cagan RL. Chemical genetic discovery of targets and anti-targets for cancer polypharmacology. Nature. 2012;486(7401):80–4.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  39. Kim GW, Won JH, Lee OK, Lee SS, Han JH, Tsogtbaatar O, Nam S, Kim Y, Cho KO. Sol narae (Sona) is a Drosophila ADAMTS involved in Wg signaling. Sci Rep. 2016;6:31863.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  40. McLean IW, Nakane PK. Periodate-lysine-paraformaldehyde fixative. A new fixation for immunoelectron microscopy. J Histochem Cytochem. 1974;22(12):1077–83.

    Article  CAS  PubMed  Google Scholar

  41. Carroll SBW, J. S. The role of the hairy gene during Drosophila morphogenesis: stripes in imaginal discs. Genes Dev. 1989;3(6):905–16.

    Article  CAS  Google Scholar

Download references

Acknowledgements

We would like to appreciate Dr. K.-W. Choi and all lab members for discussion and comments on our research, and Jean Jung and Jason Choi for editing this manuscript. We are in debt to Dr. R. A. Holmgren, Dr. G. Struhl, Dr. H. J. Bellen and especially Dr. K. H. Moberg for fly strains and antibodies. We thank Bloomington Stock Center, Drosophila Genetic Resource Center, National Institute of Genetics and Developmental Studies Hybridoma Bank. This research was supported by grants from the National Research Foundation of Korea, NRF-2017R1A2B4009254 and NRF-2019R1H1A2039726.

Funding

This research was supported by grants from the National Research Foundation of Korea, NRF-2017R1A2B4009254 and NRF-2019R1H1A2039726. The funding bodies had no role in the design of the study, the collection, analysis and interpretation of data, and writing this manuscript.

Author information

Authors and Affiliations

  1. Department of Biological Sciences, Korea Advanced Institute of Science and Technology, 291 Daehak-ro, Yuseong-gu, Daejeon, Korea

    Sujin Nam & Kyung-Ok Cho

Authors
  1. Sujin Nam
    View author publications

    You can also search for this author in PubMed Google Scholar

  2. Kyung-Ok Cho
    View author publications

    You can also search for this author in PubMed Google Scholar

Contributions

S. Nam and K.-O. Cho designed experiments, analyzed data and wrote the paper. S. Nam conducted all experiments. Both authors have read and approved this manuscript.

Corresponding author

Correspondence to Kyung-Ok Cho.

Ethics declarations

Ethics approval and consent to participate

Not applicable.

Consent for publication

Not applicable.

Competing interests

The authors declare no competing interests.

Additional information

Publisher’s Note

Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.

Supplementary information

Additional file 1: Figure S1.

Validation of myc-ago and ago dsRNA constructs. a Target regions of HM04005 and HMS00111 are marked with red bars on corresponding regions in Ago protein. b S2 cells transfected with myc-ago expressed MYC-Ago, and S2 cells cotransfected with both myc-ago and ago dsRNA did not express MYC-Ago. Endogenous Ago in S2 cells is undetectable as shown in the first lane. c The level of MYC-Ago was increased as culture time after heatshock at 37oC from 1 to 6 hours in hsp70>myc-ago larval extract.d MYC-Ago was also detected by both anti-MYC and anti-Ago antibodies in wing discs. Scale bar, 20 μm.

Additional file 2: Figure S2.

Loss or gain of Ago affects wing size. ap-Gal4 was crossed with w1118 (n=28, a), UAS-agoHM04005 (n=19, b), UAS-agoHMS00111 (n=18, c), UAS-agoUAS.ORF (n=17, d), UAS-myc-ago (n=20, e) and UAS-myc-ago UAS-agoHMS00111 (n=20, f) at 25ºC. These whole wing images were used to calculate the wing size in Fig. 1h.

Additional file 3: Figure S3.

Loss of shafts in chemosensory bristles by knockdown of ago is independent of two Ago substrates, Cyc E and dMyc. a-cneur-Gal4 was crossed with UAS-ago RNAi, UAS-cyc E or UAS-dmyc and cultured at 18ºC. Knockdown of ago induced loss of shafts in chemosensory bristles (a), but knockdown of cyc E (n=12, b) or dmyc (n=10, c) did not.

Additional file 4: Figure S4.

Wg-expressing cells are a subpopulation of C96-Gal4+ cells in DV midline. a-b Pattern of nuclear LacZ representing C96-Gal4+ cells (a') and wg-LacZ+ cells (b'). c Wing discs expressing GFP driven by C96-Gal4 and LacZ by wg-LacZ reporter. Scale bar, 20 μm.

Additional file 5: Figure S5.

Knockdown of Ago reduces the steepness of Wg gradient. ago RNAi was induced for 24 h by ap-Gal4; tub-Gal80ts. a Wing discs were obtained immediately after Gal4 induction and stained for extracellular Wg. A representative image was presented (n=5). The composite image in (a) was individually shown in (a'-a'''). Yellow line distinguishes the DV midline based on anti-Ago (a'''). b The graph shows fluorescent intensity of extracellular Wg (green line) and Ago (red line) crossing DV midline marked in (a).

Rights and permissions

Open Access This article is licensed under a Creative Commons Attribution 4.0 International License, which permits use, sharing, adaptation, distribution and reproduction in any medium or format, as long as you give appropriate credit to the original author(s) and the source, provide a link to the Creative Commons licence, and indicate if changes were made. The images or other third party material in this article are included in the article's Creative Commons licence, unless indicated otherwise in a credit line to the material. If material is not included in the article's Creative Commons licence and your intended use is not permitted by statutory regulation or exceeds the permitted use, you will need to obtain permission directly from the copyright holder. To view a copy of this licence, visit http://creativecommons.org/licenses/by/4.0/. The Creative Commons Public Domain Dedication waiver (http://creativecommons.org/publicdomain/zero/1.0/) applies to the data made available in this article, unless otherwise stated in a credit line to the data.

Reprints and permissions

About this article

Check for updates. Verify currency and authenticity via CrossMark

Cite this article

Nam, S., Cho, KO. Wingless and Archipelago, a fly E3 ubiquitin ligase and a homolog of human tumor suppressor FBW7, show an antagonistic relationship in wing development. BMC Dev Biol 20, 14 (2020). https://doi.org/10.1186/s12861-020-00217-1

Download citation

  • Received:

  • Accepted:

  • Published:

  • DOI: https://doi.org/10.1186/s12861-020-00217-1

Keywords

BMC Developmental Biology

ISSN: 1471-213X

Contact us
