Expression of ribosomopathy genes during Xenopus tropicalis embryogenesis



Because ribosomes are ubiquitously required for protein production, it was long assumed that any inherited defect in ribosome manufacture would be embryonically lethal. However, several human congenital diseases have been found to be associated with mutations in ribosome biogenesis factors. Surprisingly, despite the global requirement for ribosomes, these “ribosomopathies” are characterized by distinct and tissue specific phenotypes. The reasons for such tissue proclivity in ribosomopathies remain mysterious but may include differential expression of ribosome biogenesis factors in distinct tissues.


Here we use in situ hybridization of labeled antisense mRNA probes and ultra high temporal resolution RNA-Seq data to examine and compare expression of 13 disease associated ribosome biogenesis factors at six key stages in Xenopus tropicalis development.


Rather than being ubiquitously expressed during development, mRNAs of all examined ribosome biogenesis factors were highly enriched in specific tissues, including the cranial neural crest and ventral blood islands. Interestingly, expression of ribosome biogenesis factors demonstrates clear differences in timing, transcript number and tissue localization.


Ribosome biogenesis factor expression is more spatiotemporally regulated during embryonic development than previously expected and correlates closely with many of the common ribosomopathy phenotypes. Our findings provide information on the dynamic use of ribosome production machinery components during development and advance our understanding of their roles in disease.


Ribosomes translate genetically encoded information into proteins. Their production is a ubiquitous, carefully regulated, and energetically expensive cellular process. It is so essential to life that it alone accounts for over 60 % of total transcription in eukaryotic cells [1, 2]. While it was long assumed that any defect in this fundamental process would be incompatible with life, mutations affecting ribosome production have now been identified in several human congenital disorders (ribosomopathies) and in animal models [315]. Despite all arising from abnormalities in the ubiquitous process of ribosome biogenesis, these diseases exhibit unexpectedly unique phenotypes (Table 1) [1, 1618]. The reason for this tissue proclivity remains mysterious but its existence hints at a fundamental cell type specificity in ribosome biology during development.

Table 1 Diseases of Ribosome Biogenesis
Table 2 Sites of enriched ribosome biogenesis factor expression

Ribosome production is a complex process. Briefly summarized, each 80S ribosome is composed of two ribonucleoprotein subcomplexes. The large 60s subunit (LSU) is composed of the 28S, 5.8S and 5S ribosomal RNAs (rRNAs) and 46 associated ribosomal proteins (RPL), while the small 40S subunit (SSU) contains the 18S rRNA and 33 ribosomal proteins (RPS, Fig. 1a) [1, 18]. Production of these subunits begins in the nucleolus with the transcription of the polycistronic pre-ribosomal RNA (rRNA) by RNA polymerase I (RNAPI). This large precursor rRNA then undergoes numerous sequential cleavages, modifications and foldings to ultimately produce the mature 18S rRNA, 5.8S and 28S rRNAs. The 5S rRNA is transcribed separately by RNA polymerase III (Fig. 1a). Correct transcription and processing of the rRNAs and their assembly into the ribosomal subcomplexes requires the concerted action of all three RNA polymerases, 75 small nucleolar RNAs (snoRNAs), and over 200 ribosome biogenesis factors [1, 16, 1921]. Each of these biogenesis factors must also be transcribed by RNA polymerase II, translated by cytoplasmic ribosomes and localized correctly to carry out its function in the nucleolus, nucleus or cytoplasm (Fig. 1a) [1, 16, 18].

Fig. 1
figure 1

a Schematic of ribosome biogenesis. The rDNA is transcribed by RNA polymerase I and the resulting rRNA is processed in the nucleolus before being incorporated into the large ribosomal subunit (LSU) or small ribosomal subunit (SSU). b Schematic of X. tropicalis embryos at examined stages. Major anatomical features are labeled. A: anterior, P: posterior, D: dorsal, R: ventral

A number of human diseases are now associated with defects in ribosome production (Table 1). For example, lesions in at least 15 different ribosomal proteins (RP) underlie Diamond-Blackfan anemia (DBA, OMIM# 105650, RPL and RPS mutations) [2231]. These anomalies affect pre-rRNA processing and assembly of the SSU or LSU, and typically result in bone marrow failure. Craniofacial, growth and limb defects are also commonly present in patients [16, 22, 25]. Mutations in the ribosome biogenesis factor hUTP4 (formerly called Cirhin), cause North American Indian Childhood Cirrhosis (NAIC, OMIM# 604901, UTP4 mutations), a form of biliary cirrhosis [32, 33]. Without a liver transplant in childhood, this condition is fatal. In Shwachman-Bodian-Diamond syndrome (SBDS, OMIM# 260400), patients present with pancreatic failure, bone marrow defects and skeletal abnormalities caused by mutations in the SBDS protein that impair maturation of the large ribosomal subunit [3436]. Treacher-Collins syndrome (TCS, OMIM# 154500, typically TCOF1 mutations) is characterized primarily by craniofacial defects [1, 3, 5, 16, 18, 3739]. Other major ribosomopathies include Chromosome 5q- syndrome (5q, OMIM# 153550, acquired RPS14 mutations, macrocytic anemia) [1, 16, 40], Alopecia, Neurological and Endocrinopathy syndrome (ANE, OMIM# 612079, RBM28 mutations) [41], and isolated congenital asplenia (ICA, OMIM# 271400, RPSA mutations), that specifically impairs spleen development [42]. Numerous additional confirmed and suspected ribosomopathies exist (Table 1). While some of the ribosomopathies have defects in common (e.g. anemia, growth retardation, craniofacial defects, increased risk of cancer), these diseases are clinically distinct and difficult to treat. Understanding their etiology is a first step towards improving treatment options and patient prognosis.

Why defects in the ubiquitous production of ribosomes lead to tissue specific phenotypes remains a fascinating and clinically important question. One possibility is that the affected tissues are simply rapidly dividing and are thus more sensitive to reduced ribosome numbers. However, this does not account for the non-overlapping phenotypes observed in these syndromes, or explain why some highly active populations appear unaffected. Other proposed mechanisms include 1) selective translation of mRNAs with internal ribosome entry sites and 2) extra ribosomal functions specific to each protein [16, 4348]. One intriguing possibility that may explain the diverse effects of ribosomal protein abnormality is that ribosomes are tailored to translate specific mRNAs, or have particular properties in different cell types. Changes in ribosomal composition and biogenesis may then affect these activities. In support, reduction of Rpl38 in mice can alter the composition of Hox gene mRNAs translation and embryonic patterning, without reducing overall protein synthesis [6]. Furthermore, ribosomal gene mRNA expression exhibits significant variation across tissues [6, 46, 47, 4951]. Such variation may result in differential ribosome production and activity. This idea of specialized ribosomes challenges our notion of ribosomes as monolithic entities and may suggest a fundamental mechanism of translational regulation. However, a comprehensive spatiotemporal understanding of ribosomopathy associated gene expression during development is not known, which is essential to correlate with the tissue proclivity observed in ribosomopathies.

As a preliminary step in examining this issue, we analyzed the expression of thirteen distinct ribosome biogenesis factors (rps7, 14, 17, 19, 29, rpl15, 26, 35a, 38, tcof1, rbm28, sbds and utp4) using whole mount in situ hybridization and ultra high temporal resolution RNA-Seq data. Mutations in twelve of these factors are implicated in six phenotypically distinct human conditions. We found that expression of these genes is greatly upregulated in specific tissues during development, particularly in the cranial neural crest (CNC) and ventral mesoderm, and broadly correlates with common ribosome disease phenotypes. While the general pattern of expression is similar for all examined genes, unexpected differences do exist. Overall our study reveals extensive spatiotemporal regulation of ribosome biogenesis factor expression during embryonic development.


Xenopus embryos

X. tropicalis were maintained and cared for in our aquatics facility, in accordance with Yale University Institutional Animal Care and Use Committee protocols. Embryos were produced by in vitro fertilization and raised to appropriate stages in 1/9MR + gentamycin [52].

Whole-mount in situ hybridization

Full length clones for; rbm28, TTpA003i23; rpl15, IMAGE: 7606910; rpl26, TNeu089l11; rpl35a, TNeu023b09; rpl38, TNeu074p13; rps7, TNeu091o12; rps14, IMAGE: 8896584; rps17, TNeu101k22; rps19, TNeu108f02; rps29, TGas050g16; sbds, TGas062n22; tcof1 TEgg112k11, and upt4, TGas051c03 were obtained in pCS107 vector from the Sanger/Wellcome Trust Xenopus tropicalis cDNA libraries. Digoxigenin-labeled antisense mRNA probes were in vitro transcribed with T7 High Yield RNA Synthesis Kit (E2040S) from New England Biolabs. Embryos were collected at desired stages, fixed in MEMFA for 1–2 h at room temperature and dehydrated into 100 % ETOH. Whole mount in situ hybridization was performed as described previously [4, 53]. Embryos were stained with BM Purple and examined after equilibration in 100 % glycerol.

High temporal resolution RNA-Seq

Gene expression trajectories were compared using our previously published RNA-seq data [54] (GEO: GSE65785), which reports gene expression in absolute transcripts per embryo. X. tropicalis v7.1 models as used in [54] for rpl15, rpl26, rpl35a, rpl38, rps7, rps17, rps19 were found to be incorrect, and were corrected with reference to reads and gene models from X. tropicalis v4 assembly. Corrected gene models are available in Additional file 1. Gene expression abundances in absolute transcripts per embryo were re-quantified with improved models as described in [54].


To study expression of ribosome biogenesis factors during embryonic development, we examined six key developmental stages: 3, 10, 15, 20–22, 28–30, and 36–40 (Fig. 1b). These stages mark critical time points during embryogenesis, including maternal RNA inheritance, germ layer specification, morphogenesis and organogenesis. We examined gene expression in numerous anatomical structures including the neural tube, streams of migrating neural crest, pharyngeal arches, heart, eye, ventral mesoderm, and pronephros (described in Fig. 1b). In situ hybridizations using digoxigenin labeled sense mRNA probes for each gene were carried out as controls (Additional file 2).

Expression of ribosome biogenesis factors

We began by examining the expression patterns of four ribosome biogenesis factors that have previously been implicated in phenotypically distinct human malformations, tcof1, rbm28, sbds, and utp4.

With the exception of tcof1, signal for each factor was weakly detected at the 4-cell stage and in the animal pole surrounding the blastopore at stage 10. Interestingly, tcof1 expression appeared much more robust in these tissues (Fig. 2a). At stage 16 expression of all genes was strongly associated with the anterior neural plate and neural fold borders where CNC form. At stage 22 transcripts were robustly detected in the migrating CNC and the posterior region of the neural tube. Expression was typically much weaker or absent in the intermediate regions of the neural tube. Uniquely, utp4 transcripts were detected in the ventral mesoderm at this stage (Fig. 2a).

Fig. 2
figure 2

Expression of disease-linked ribosome biogenesis factors in X. tropicalis embryos. a Expression of all four genes was detected in the 4-cell and gastrulating embryo. Signal was strongly detected in the neural folds at stage 16 and in the migrating neural crest at stage 22. b At later stages expression of all factors was detected in the facial primordia and developing brain. Note the restricted expression at the mid–hindbrain border and forebrain. Expression was also typically detected in ventral mesoderm and hypaxial muscle precursor cells. utp4 mRNA was strongly detected at the site of the future liver. c Red lines labeled a*, b* and c* in diagrams of stage 10 and 28 embryos represent the planes of section shown in a and b

At stage 28 all four ribosome biogenesis factors were similarly expressed in the CNC populated craniofacial regions as well as the developing eye and otic placode (Fig. 2b). Interestingly, expression within the developing brain appeared strong and spatially restricted at the mid – hindbrain border (a crucial signaling center) and in discreet regions of the forebrain. Expression of rbm28, tcof1 and utp4 also appeared enriched in the posterior neural tube and tail bud, while expression of sbds was more uniform along the length of the neural tube. tcof1 and rbm28 were also detected in hypaxial muscle and the ventral mesoderm/blood island region (Fig. 2b). Coronal sections through the craniofacial region revealed strong and specific expression of each gene within the mandibular, hyoid and branchial CNC populated pharyngeal arches, while transverse sections through the trunk confirmed expression in the neural tube (Fig. 2b). At stage 36–40 this precise spatial regulation of expression was largely maintained. tcof1 and rbm28 were expressed strongly in the CNC populated facial regions, the developing ear, and strongly in the mid-hindbrain and fore-midbrain boundaries. Their expression appeared significantly less robust, or absent, in other regions of the brain and neural tube. Interestingly, sbds was detected much more broadly throughout the craniofacial region and neural tube at these stages while utp4 expression was greatly enriched specifically in the head. While all assayed genes were detected diffusely in the region of heart and liver at stage 36, utp4 expression was observed in this region at stage 28 and was notably broad and robust here at stage 36–40 (Fig. 2b).

Expression of rps genes: rps7, 14, 17, 19, 29

We next examined the expression of several key RPS genes. RPS 7, 17, 19 and 29 are all associated with Diamond-Blackfan anemia, which is principally characterized by defects in bone marrow, craniofacial and limb development. RPS14 mutations underlie 5q- syndrome, an acquired ribosomopathy that is characterized by macrocytic anemia and cancer predisposition.

At the 4-cell stage we detected variable amounts of maternal rps transcripts. rps7 revealed little or no signal in the animal pole, while rps14 signal was relatively strong. rps17, 19 and 29 each displayed intermediate levels of staining (Fig. 3a). At stage 10, shortly after the maternal to zygotic transition, all RPS genes examined exhibited comparably diffuse signal around the blastopore of whole mount gastrulating embryos. Expression of rps7 appeared more robust in the animal tissues when embryos were sectioned (Fig. 3a). At stage 15 expression of all genes was detected within the neural folds and border regions where the CNC are being induced. At stages 18–22 the examined rps genes were expressed in the neural tube, developing brain and migrating neural crest. Interestingly, rps7 transcripts were more highly detected in the somites when compared to other rps mRNAs (Fig. 3a).

Fig. 3
figure 3

rps genes are dynamically expressed in development. a Expression of all five rps genes examined was observed in the stage 10 gastrula, stage 16 neural folds, and migrating CNC at stage 20–22. b Each gene was widely detected in the developing head at later stages (28–40), including all the pharyngeal arches, brain, eyes and ears. rps17, 19 and 29 were also robustly detected in the ventral mesoderm, while rps7 was particularly defined in somites. With the exception of rps7, transcripts of all mRNAs were detected in the dorso-lateral plate mesodermal region where the pronephros and hypaxial muscle will form. c Red lines labeled a*, b* and c* in diagrams of stage 10 and 28 embryos represent the planes of section shown in a and b

At stage 28, all were robustly expressed throughout the craniofacial regions, including the CNC populated mandibular, hyoid, anterior and posterior pharyngeal arches, forebrain, midbrain, hindbrain, otic and optic placodes. Interestingly, we detected signal in the dorso-lateral plate mesodermal region where the pronephic tubule and hypaxial muscle will form in rps14, 17, 19 and 29, but this signal was not observed in rps7 (Fig. 3b). However, rps7 expression in the somites continued to be much more defined than that of other RPS genes. Robust expression of rps17, 19 and 29 was also detected in the heart and ventral mesoderm/blood island regions at this stage suggesting a possible role in hematopoiesis, while expression of rps7 was not evident in the ventral blood islands, and rps14 was not detected in the heart or blood islands (Fig. 3b). By stages 36–40 rps17, 19 and 29 were ubiquitously detected throughout the embryo, while rps7 and 14 were absent from ventral regions.

Expression of rpl genes: rpl15, 26, 35a, and 38

Mutations in numerous RPL genes have also been implicated in DBA. Here we examine the developmental expression pattern of three such rpl genes (15, 26 & 35a). We also compare expression of rpl38, which has not yet been identified in human disease but heterozygous loss in mice results in anemia and skeletal malformations [6].

Expression of all assayed rpl genes was weak or absent at 4-cells. rpl15 and rpl26 expression was also undetected at gastrulation stages, while rpl35a and rpl38 were clearly evident in the animal pole (Fig. 4a). Interestingly, while rpl26, rpl35a and rpl38 transcripts were strongly detected in the neural folds at stage 16, rpl15 remained absent. At stage 22 rpl26, rpl35a and rpl38 mRNA were detected in the developing brain, neural tube and migrating neural crest (Fig. 4a). rpl38 also exhibited very defined expression domains within the somites. Expression of rpl15 continued to be very low or absent at this stage.

Fig. 4
figure 4

Expression of rpl genes. a rpl mRNA was weakly detected or absent at early stages of development but, with the exception of rpl15, became up-regulated in the neural folds and migratory neural crest from neurula stages onwards. b At later stages expression of all four rpl genes was evident broadly throughout the head, pharyngeal arches, neural tube and ventral mesoderm/blood islands. c Red lines labeled a*, b* and c* in diagrams of stage 10 and 28 embryos represent the planes of section shown in a and b

By stage 28, expression of all four rpl genes was strongly associated with the developing brain, neural tube, all pharyngeal arches, otic and optic placodes, developing heart field and ventral mesoderm/blood islands. This pattern was broadly maintained at stage 36–40. Expression of rpl26 and rpl38 appeared ubiquitous at these stages (Fig. 4b).

High temporal resolution RNA-seq analysis

We previously created a genome-wide RNA-seq dataset with ultra high temporal resolution [54]. This dataset allows precise measurement of absolute transcripts per embryos, and comparison of expression dynamics for the entire transcriptome during Xenopus development. Here we utilized this rich resource to measure ribosome associated gene transcript kinetics in the embryo.

Ribosomopathy associated genes displayed significant variation in transcript numbers and expression dynamics throughout embryogenesis. While all RP genes examined exhibited a similar dynamic, evident as a continuous increase in expression as the embryo grows, there were pronounced differences in absolute transcript numbers (Fig. 5a). Ribosome biogenesis factor genes were expressed at lower levels than rpl or rps mRNAs and exhibited highly dynamic and regulated expression profiles (Fig. 5b). This was evident both in the number of transcripts and in the temporal regulation of expression (compare sbds and rbm28 for example). Interestingly these biogenesis factors generally exhibited three, variably pronounced, peaks of expression during development suggesting increased biological demand at these stages (red arrows, Fig. 5b). The first peak occurs during early gastrulation stages as the embryo undergoes the complex cell movements and differentiations required to correctly establish the germ layers. The second peak occurs between stages 22–28, an extremely active developmental window marked by cell migrations, differentiation, rapid growth, and morphological change (Fig. 5b). Similarly, a third expression peak was evident at stage 36–45, a time of pronounced organogenesis and activity.

Fig. 5
figure 5

Dynamics of gene expression of poly(A) + mRNA in transcripts per embryo . a Plot of all examined genes. Note the relatively consistent dynamics but variably levels of of RP gene transcription. b Expression dynamics of ribosome biogenesis factors. While variable, three pronounced peaks in expression are evident during development (red arrows). c Expression of individual biogenesis factors


Ribosomes are generally thought of as monolithic cellular machines, ubiquitously expressed and functionally identically in every cell and tissue. However, an emerging body of research suggests that this is not the case. In particular, the diverse tissue specific phenotypes observed in human ribosomopathies and animal models point to an intriguing variation in requirements for ribosome biogenesis factors and/or ribosome biology during development [1, 4, 6, 7, 16, 25, 32, 36, 42, 46, 47, 50]. Here, we examined the developmental expression patterns of 13 ribosome-associated genes in Xenopus. With the exception of rpl38, the human orthologue of each of these has been implicated in disease. We found that ribosome-associated genes are not ubiquitously expressed during Xenopus development. Instead expression of components of the ribosome production machinery was highly spatiotemporally regulated, suggesting tissue specific activity.

All examined ribosome biogenesis factors were expressed in generally similar and dynamic spatial patterns. This included strong expression in the cranial neural crest, pharyngeal arches arches, eye and ears. Expression was also commonly detected within the developing brain, neural tube and ventral blood islands (summarized in Table 2). While overall patterns were similar, surprising differences were noted in both location and quantity of transcripts. For example, rps7 transcripts were strongly detected in the somites at stage 22 but not in the developing kidney or hypaxial muscle at stage 28, while rps14, 19 and 29 were the opposite. Even more striking was the clear restriction of ribosome biogenesis factor expression compared to constituents of the LSU and SSU (rps and rpl genes). At stage 22 these biogenesis factors (Fig. 1) were typically greatly enriched in the anterior and posterior regions of the neural tube while rps and rpl transcripts were more evenly distributed. Moreover, at stage 28 their expression in the head was largely restricted to the CNC, eye, ear and mid-hindbrain boundary compared to the much broader craniofacial expression of rpl and rps genes (compare Fig. 2 vs. Figs. 3 and 4). Transcript number and expression kinetics also varied dramatically over time, hinting at unexpected stoichiometric relationships in ribosome production. Interestingly, the rhythmic expression observed in biogenesis factors, particularly rbm28, is similar to the dynamics of circadian genes. This observation fits well with previous reports that the circadian clock regulates ribosome biogenesis and mRNA translation [55]. These restricted and varied expression patterns are suggestive of tissue specific requirements and together with previous studies [6, 51, 55] suggest a greater dynamism of ribosome production genes than generally assumed.

The expression patterns observed also correlate closely with common ribosomopathy phenotypes. For example, craniofacial defects and macrocytic anemia are frequent features of ribosomopathies, particularly DBA and TCS [3, 5, 18, 22, 23, 37, 43]. We found expression of all 15 ribosome production genes to be strongly associated with the CNC and developing head. The sensitivity of the CNC to perturbations in ribosome production has been noted in both human patients and in animal models [35, 7], where it often appears to trigger a nucleolar stress response leading to increased apoptosis within the developing CNC and other tissues [4, 5, 7, 13, 45, 5658]. The consistent and robust expression of all 15 examined ribosome associated genes in the CNC and head provides further evidence of a high ribosomal requirement in these tissues and suggest that ribosomal defects may contribute to unexplained craniofacial malformations. The majority of gene transcripts were also detected in the ventral mesoderm, in the region of the ventral blood islands. This compartment makes a critical contribution to the erythrocyte population in the developing tadpole [59, 60]. While bone marrow is not yet formed in the tadpole at the stages examined, this expression is consistent with a role in red blood cell development. Several other genes also overlapped with their clinical phenotypes. For example, rbm28 expression in the developing brain and utp4 expression at the site of the future liver correlate with disease phenotype.

However, later stage embryonic expression patterns alone do not accurately predict disease phenotype, as all examined genes display broadly similar expression but are associated with phenotypically distinct diseases. For example, we detected utp4 in the craniofacial regions similar to tcof1, rpl and rps genes. However, its mutation in humans and knockdown in zebrafish lead specifically to a failure in liver development [1, 8, 32]. In comparison tcof1 mutation is characterized by craniofacial malformations, while rpl/rps mutations often produce a broader range of abnormalities, including anemia, craniofacial and growth defects [1, 3, 5, 8, 10, 1416, 22, 23, 32, 34, 37, 43]. Expression at earlier stages of development, or the availability of maternal derived protein, may partially explain this apparent paradox. Interestingly, our RNA-Seq and in situ data suggest relatively high levels of maternal tcof1 transcript at early developmental times relative to rps/rpl genes. Thus, there may be sufficient Tcof1 present to meet early developmental requirements, such as hematopoietic stem cell specification, but not later CNC demands. This early enrichment of tcof1 and relative paucity of rp gene expression has also been observed in zebrafish [10, 25, 39], suggesting it is an evolutionary conserved feature. In future studies, it would be informative to further assay initial levels of maternal transcript or protein and determine if this correlates with the timing of phenotype.

The biological reasoning behind these restricted gene expression patterns, and their mechanistic contribution to disease remain unclear. It is possible that these tissues are highly active and require greater numbers of ribosomes, which in turn makes them more sensitive to ribosome biogenesis defects. However, it is then surprising that we do not see expression in other active and rapidly dividing tissues at these stages, or identical expression patterns for all the ribosome biogenesis factors examined. Several ribosome biogenesis factors and proteins have extra-ribosomal functions [16, 19, 44, 48, 6163], or roles in selective translation of internal ribosome entry site mRNAs [16, 43, 46, 47, 64], which may also contribute to ribosomopathy phenotypes. “Specialized ribosomes”, tailored to preferentially translate specific mRNAs, or to have specific properties in particular environments are another possibility [6, 16, 17, 25, 46, 47, 50]. Support for this is found primarily in observations that ribosomal gene expression levels do vary between tissues [6, 7, 49, 51, 65, 66], and direct evidence of a regulatory role for individual RP proteins in selective mRNA translation and embryonic tissue patterning [6, 16, 43, 49, 50]. Furthermore, in Dictyostelium ribosome composition appears to shift with cell cycle [67, 68]. These findings suggest that ribosomes are not ubiquitously identical machines. Our observation of differential ribosome biogenesis factor expression during development provides additional support for this idea.


While not new, the concept of specialized ribosomes is potentially a paradigm shifting advancement in our understanding of the fundamental interactions between ribosome biology, translation, cell cycle and embryonic development. Such topics are the focus of ongoing investigations and promise to greatly enhance our knowledge of a core biological process and a severe class of human diseases. In demonstrating the highly regulated and varied expression patterns of ribosomopathy genes during embryonic development, our results provide further support for the existence of tissue specific ribosomal requirements or functions, which may contribute to the startling tissue proclivity of ribosomopathies.



Cranial neural crest


Diamond-Blackfan anemia


North American Indian Childhood Cirrhosis


RNA Binding Motif Protein 28


Ribosomal protein


Shwachman-Bodian-Diamond Syndrome (Protein)


Treacle ribosome biogenesis factor 1


  1. Freed EF, Bleichert F, Dutca LM, Baserga SJ. When ribosomes go bad: diseases of ribosome biogenesis. Mol BioSyst. 2010;6(3):481–93.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  2. Warner JR, Vilardell J, Sohn JH. Economics of ribosome biosynthesis. Cold Spring Harb Symp Quant Biol. 2001;66:567–74.

    Article  CAS  PubMed  Google Scholar

  3. Dixon J, Jones NC, Sandell LL, Jayasinghe SM, Crane J, Rey JP, Dixon MJ, Trainor PA. Tcof1/Treacle is required for neural crest cell formation and proliferation deficiencies that cause craniofacial abnormalities. Proc Natl Acad Sci U S A. 2006;103(36):13403–8.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  4. Griffin JN, Sondalle SB, Del Viso F, Baserga SJ, Khokha MK. The ribosome biogenesis factor Nol11 is required for optimal rDNA transcription and craniofacial development in Xenopus. PLoS Genet. 2015;11(3):e1005018.

    Article  PubMed  PubMed Central  Google Scholar

  5. Jones NC, Lynn ML, Gaudenz K, Sakai D, Aoto K, Rey JP, Glynn EF, Ellington L, Du C, Dixon J, et al. Prevention of the neurocristopathy Treacher Collins syndrome through inhibition of p53 function. Nat Med. 2008;14(2):125–33.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  6. Kondrashov N, Pusic A, Stumpf CR, Shimizu K, Hsieh AC, Xue S, Ishijima J, Shiroishi T, Barna M. Ribosome-mediated specificity in Hox mRNA translation and vertebrate tissue patterning. Cell. 2011;145(3):383–97.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  7. Zhao C, Andreeva V, Gibert Y, LaBonty M, Lattanzi V, Prabhudesai S, Zhou Y, Zon L, McCann KL, Baserga S, et al. Tissue specific roles for the ribosome biogenesis factor Wdr43 in zebrafish development. PLoS Genet. 2014;10(1):e1004074.

    Article  PubMed  PubMed Central  Google Scholar

  8. Wilkins BJ, Lorent K, Matthews RP, Pack M. p53-mediated biliary defects caused by knockdown of cirh1a, the zebrafish homolog of the gene responsible for North American Indian Childhood Cirrhosis. PLoS One. 2013;8(10):e77670.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  9. Amsterdam A, Nissen RM, Sun Z, Swindell EC, Farrington S, Hopkins N. Identification of 315 genes essential for early zebrafish development. Proc Natl Acad Sci U S A. 2004;101(35):12792–7.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  10. Danilova N, Sakamoto KM, Lin S. Ribosomal protein L11 mutation in zebrafish leads to haematopoietic and metabolic defects. Br J Haematol. 2011;152(2):217–28.

    Article  CAS  PubMed  Google Scholar

  11. Devlin EE, Dacosta L, Mohandas N, Elliott G, Bodine DM. A transgenic mouse model demonstrates a dominant negative effect of a point mutation in the RPS19 gene associated with Diamond-Blackfan anemia. Blood. 2010;116(15):2826–35.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  12. Kongsuwan K, Yu Q, Vincent A, Frisardi MC, Rosbash M, Lengyel JA, Merriam J. A Drosophila Minute gene encodes a ribosomal protein. Nature. 1985;317(6037):555–8.

    Article  CAS  PubMed  Google Scholar

  13. McGowan KA, Li JZ, Park CY, Beaudry V, Tabor HK, Sabnis AJ, Zhang W, Fuchs H, de Angelis MH, Myers RM, et al. Ribosomal mutations cause p53-mediated dark skin and pleiotropic effects. Nat Genet. 2008;40(8):963–70.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  14. Uechi T, Nakajima Y, Chakraborty A, Torihara H, Higa S, Kenmochi N. Deficiency of ribosomal protein S19 during early embryogenesis leads to reduction of erythrocytes in a zebrafish model of Diamond-Blackfan anemia. Hum Mol Genet. 2008;17(20):3204–11.

    Article  CAS  PubMed  Google Scholar

  15. Zhang Y, Ear J, Yang Z, Morimoto K, Zhang B, Lin S. Defects of protein production in erythroid cells revealed in a zebrafish Diamond-Blackfan anemia model for mutation in RPS19. Cell Death Dis. 2014;5:e1352.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  16. Armistead J, Triggs-Raine B. Diverse diseases from a ubiquitous process: the ribosomopathy paradox. FEBS Lett. 2014;588(9):1491–500.

    Article  CAS  PubMed  Google Scholar

  17. McCann KL, Baserga SJ. Genetics. Mysterious ribosomopathies. Science. 2013;341(6148):849–50.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  18. Sondalle SB, Baserga SJ. Human diseases of the SSU processome. Biochim Biophys Acta. 2014;1842(6):758–64.

    Article  CAS  PubMed  Google Scholar

  19. Gallagher JE, Dunbar DA, Granneman S, Mitchell BM, Osheim Y, Beyer AL, Baserga SJ. RNA polymerase I transcription and pre-rRNA processing are linked by specific SSU processome components. Genes Dev. 2004;18(20):2506–17.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  20. Granneman S, Baserga SJ. Ribosome biogenesis: of knobs and RNA processing. Exp Cell Res. 2004;296(1):43–50.

    Article  CAS  PubMed  Google Scholar

  21. Henras AK, Soudet J, Gerus M, Lebaron S, Caizergues-Ferrer M, Mougin A, Henry Y. The post-transcriptional steps of eukaryotic ribosome biogenesis. Cell Mol Life Sci. 2008;65(15):2334–59.

    Article  CAS  PubMed  Google Scholar

  22. Clinton C, Gazda HT. Diamond-Blackfan Anemia. In: Pagon RA, Adam MP, Ardinger HH, Wallace SE, Amemiya A, Bean LJH, Bird TD, Fong CT, Mefford HC, Smith RJH et al, editors. GeneReviews(R). Seattle: University of Washington; 1993.

  23. Ball SE, McGuckin CP, Jenkins G, Gordon-Smith EC. Diamond-Blackfan anaemia in the U.K.: analysis of 80 cases from a 20-year birth cohort. Br J Haematol. 1996;94(4):645–53.

    Article  CAS  PubMed  Google Scholar

  24. Gazda HT, Sheen MR, Vlachos A, Choesmel V, O’Donohue MF, Schneider H, Darras N, Hasman C, Sieff CA, Newburger PE, et al. Ribosomal protein L5 and L11 mutations are associated with cleft palate and abnormal thumbs in Diamond-Blackfan anemia patients. Am J Hum Genet. 2008;83(6):769–80.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  25. Danilova N, Gazda HT. Ribosomopathies: how a common root can cause a tree of pathologies. Dis Model Mech. 2015;8(9):1013–26.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  26. Boria I, Garelli E, Gazda HT, Aspesi A, Quarello P, Pavesi E, Ferrante D, Meerpohl JJ, Kartal M, Da Costa L, et al. The ribosomal basis of Diamond-Blackfan Anemia: mutation and database update. Hum Mutat. 2010;31(12):1269–79.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  27. Farrar JE, Quarello P, Fisher R, O’Brien KA, Aspesi A, Parrella S, Henson AL, Seidel NE, Atsidaftos E, Prakash S, et al. Exploiting pre-rRNA processing in Diamond Blackfan anemia gene discovery and diagnosis. Am J Hematol. 2014;89(10):985–91.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  28. Gazda HT, Preti M, Sheen MR, O’Donohue MF, Vlachos A, Davies SM, Kattamis A, Doherty L, Landowski M, Buros C, et al. Frameshift mutation in p53 regulator RPL26 is associated with multiple physical abnormalities and a specific pre-ribosomal RNA processing defect in diamond-blackfan anemia. Hum Mutat. 2012;33(7):1037–44.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  29. Landowski M, O’Donohue MF, Buros C, Ghazvinian R, Montel-Lehry N, Vlachos A, Sieff CA, Newburger PE, Niewiadomska E, Matysiak M, et al. Novel deletion of RPL15 identified by array-comparative genomic hybridization in Diamond-Blackfan anemia. Hum Genet. 2013;132(11):1265–74.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  30. Mirabello L, Macari ER, Jessop L, Ellis SR, Myers T, Giri N, Taylor AM, McGrath KE, Humphries JM, Ballew BJ, et al. Whole-exome sequencing and functional studies identify RPS29 as a novel gene mutated in multicase Diamond-Blackfan anemia families. Blood. 2014;124(1):24–32.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  31. Wang R, Yoshida K, Toki T, Sawada T, Uechi T, Okuno Y, Sato-Otsubo A, Kudo K, Kamimaki I, Kanezaki R, et al. Loss of function mutations in RPL27 and RPS27 identified by whole-exome sequencing in Diamond-Blackfan anaemia. Br J Haematol. 2015;168(6):854–64.

    Article  CAS  PubMed  Google Scholar

  32. Chagnon P, Michaud J, Mitchell G, Mercier J, Marion JF, Drouin E, Rasquin-Weber A, Hudson TJ, Richter A. A missense mutation (R565W) in cirhin (FLJ14728) in North American Indian childhood cirrhosis. Am J Hum Genet. 2002;71(6):1443–9.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  33. Freed EF, Baserga SJ. The C-terminus of Utp4, mutated in childhood cirrhosis, is essential for ribosome biogenesis. Nucleic Acids Res. 2010;38(14):4798–806.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  34. Ganapathi KA, Austin KM, Lee CS, Dias A, Malsch MM, Reed R, Shimamura A. The human Shwachman-Diamond syndrome protein, SBDS, associates with ribosomal RNA. Blood. 2007;110(5):1458–65.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  35. Shimamura A. Shwachman-Diamond syndrome. Semin Hematol. 2006;43(3):178–88.

    Article  CAS  PubMed  Google Scholar

  36. Boocock GR, Morrison JA, Popovic M, Richards N, Ellis L, Durie PR, Rommens JM. Mutations in SBDS are associated with Shwachman-Diamond syndrome. Nat Genet. 2003;33(1):97–101.

    Article  CAS  PubMed  Google Scholar

  37. Gonzales B, Henning D, So RB, Dixon J, Dixon MJ, Valdez BC. The Treacher Collins syndrome (TCOF1) gene product is involved in pre-rRNA methylation. Hum Mol Genet. 2005;14(14):2035–43.

    Article  CAS  PubMed  Google Scholar

  38. Valdez BC, Henning D, So RB, Dixon J, Dixon MJ. The Treacher Collins syndrome (TCOF1) gene product is involved in ribosomal DNA gene transcription by interacting with upstream binding factor. Proc Natl Acad Sci U S A. 2004;101(29):10709–14.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  39. Weiner AM, Scampoli NL, Calcaterra NB. Fishing the molecular bases of Treacher Collins syndrome. PLoS One. 2012;7(1):e29574.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  40. Ebert BL, Pretz J, Bosco J, Chang CY, Tamayo P, Galili N, Raza A, Root DE, Attar E, Ellis SR, et al. Identification of RPS14 as a 5q- syndrome gene by RNA interference screen. Nature. 2008;451(7176):335–9.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  41. Nousbeck J, Spiegel R, Ishida-Yamamoto A, Indelman M, Shani-Adir A, Adir N, Lipkin E, Bercovici S, Geiger D, van Steensel MA, et al. Alopecia, neurological defects, and endocrinopathy syndrome caused by decreased expression of RBM28, a nucleolar protein associated with ribosome biogenesis. Am J Hum Genet. 2008;82(5):1114–21.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  42. Bolze A, Mahlaoui N, Byun M, Turner B, Trede N, Ellis SR, Abhyankar A, Itan Y, Patin E, Brebner S, et al. Ribosomal protein SA haploinsufficiency in humans with isolated congenital asplenia. Science. 2013;340(6135):976–8.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  43. Horos R, Ijspeert H, Pospisilova D, Sendtner R, Andrieu-Soler C, Taskesen E, Nieradka A, Cmejla R, Sendtner M, Touw IP, et al. Ribosomal deficiencies in Diamond-Blackfan anemia impair translation of transcripts essential for differentiation of murine and human erythroblasts. Blood. 2012;119(1):262–72.

    Article  CAS  PubMed  Google Scholar

  44. DiGiacomo V, Meruelo D. Looking into laminin receptor: critical discussion regarding the non-integrin 37/67-kDa laminin receptor/RPSA protein. Biol Rev Camb Philos Soc. 2016;91:288–310.

  45. Chen D, Zhang Z, Li M, Wang W, Li Y, Rayburn ER, Hill DL, Wang H, Zhang R. Ribosomal protein S7 as a novel modulator of p53-MDM2 interaction: binding to MDM2, stabilization of p53 protein, and activation of p53 function. Oncogene. 2007;26(35):5029–37.

    Article  CAS  PubMed  Google Scholar

  46. Shi Z, Barna M. Translating the genome in time and space: specialized ribosomes, RNA regulons, and RNA-binding proteins. Annu Rev Cell Dev Biol. 2015;31:31–54.

    Article  CAS  PubMed  Google Scholar

  47. Xue S, Barna M. Specialized ribosomes: a new frontier in gene regulation and organismal biology. Nat Rev Mol Cell Biol. 2012;13(6):355–69.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  48. Bonnart C, Gerus M, Hoareau-Aveilla C, Kiss T, Caizergues-Ferrer M, Henry Y, Henras AK. Mammalian HCA66 protein is required for both ribosome synthesis and centriole duplication. Nucleic Acids Res. 2012;40(13):6270–89.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  49. Wong QW, Li J, Ng SR, Lim SG, Yang H, Vardy LA. RPL39L is an example of a recently evolved ribosomal protein paralog that shows highly specific tissue expression patterns and is upregulated in ESCs and HCC tumors. RNA Biol. 2014;11(1):33–41.

    Article  CAS  PubMed  Google Scholar

  50. Dinman JD. Pathways to Specialized Ribosomes: The Brussels Lecture. J Mol Biol. 2016;428(10 Pt B):2186–94.

    Article  CAS  PubMed  Google Scholar

  51. Bortoluzzi S, d’Alessi F, Romualdi C, Danieli GA. Differential expression of genes coding for ribosomal proteins in different human tissues. Bioinformatics. 2001;17(12):1152–7.

    Article  CAS  PubMed  Google Scholar

  52. del Viso F, Khokha M. Generating diploid embryos from Xenopus tropicalis. Methods Mol Biol. 2012;917:33–41.

    Article  PubMed  Google Scholar

  53. Khokha MK, Chung C, Bustamante EL, Gaw LW, Trott KA, Yeh J, Lim N, Lin JC, Taverner N, Amaya E, et al. Techniques and probes for the study of Xenopus tropicalis development. Dev Dyn. 2002;225(4):499–510.

    Article  CAS  PubMed  Google Scholar

  54. Owens ND, Blitz IL, Lane MA, Patrushev I, Overton JD, Gilchrist MJ, Cho KW, Khokha MK. Measuring absolute RNA copy numbers at high temporal resolution reveals transcriptome kinetics in development. Cell Rep. 2016;14(3):632–47.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  55. Jouffe C, Cretenet G, Symul L, Martin E, Atger F, Naef F, Gachon F. The circadian clock coordinates ribosome biogenesis. PLoS Biol. 2013;11(1):e1001455.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  56. Azuma M, Toyama R, Laver E, Dawid IB. Perturbation of rRNA synthesis in the bap28 mutation leads to apoptosis mediated by p53 in the zebrafish central nervous system. J Biol Chem. 2006;281(19):13309–16.

    Article  CAS  PubMed  Google Scholar

  57. Holzel M, Orban M, Hochstatter J, Rohrmoser M, Harasim T, Malamoussi A, Kremmer E, Langst G, Eick D. Defects in 18 S or 28 S rRNA processing activate the p53 pathway. J Biol Chem. 2010;285(9):6364–70.

    Article  PubMed  PubMed Central  Google Scholar

  58. Barlow JL, Drynan LF, Hewett DR, Holmes LR, Lorenzo-Abalde S, Lane AL, Jolin HE, Pannell R, Middleton AJ, Wong SH, et al. A p53-dependent mechanism underlies macrocytic anemia in a mouse model of human 5q- syndrome. Nat Med. 2010;16(1):59–66.

    Article  CAS  PubMed  Google Scholar

  59. Chen XD, Turpen JB. Intraembryonic origin of hepatic hematopoiesis in Xenopus laevis. J Immunol. 1995;154(6):2557–67.

    CAS  PubMed  Google Scholar

  60. Maeno M, Tochinai S, Katagiri C. Differential participation of ventral and dorsolateral mesoderms in the hemopoiesis of Xenopus, as revealed in diploid-triploid or interspecific chimeras. Dev Biol. 1985;110(2):503–8.

    Article  CAS  PubMed  Google Scholar

  61. Mitchell JR, Wood E, Collins K. A telomerase component is defective in the human disease dyskeratosis congenita. Nature. 1999;402(6761):551–5.

    Article  CAS  PubMed  Google Scholar

  62. Dragon F, Gallagher JE, Compagnone-Post PA, Mitchell BM, Porwancher KA, Wehner KA, Wormsley S, Settlage RE, Shabanowitz J, Osheim Y, et al. A large nucleolar U3 ribonucleoprotein required for 18S ribosomal RNA biogenesis. Nature. 2002;417(6892):967–70.

    Article  CAS  PubMed  Google Scholar

  63. Piddubnyak V, Rigou P, Michel L, Rain JC, Geneste O, Wolkenstein P, Vidaud D, Hickman JA, Mauviel A, Poyet JL. Positive regulation of apoptosis by HCA66, a new Apaf-1 interacting protein, and its putative role in the physiopathology of NF1 microdeletion syndrome patients. Cell Death Differ. 2007;14(6):1222–33.

    Article  CAS  PubMed  Google Scholar

  64. Yoon A, Peng G, Brandenburger Y, Zollo O, Xu W, Rego E, Ruggero D. Impaired control of IRES-mediated translation in X-linked dyskeratosis congenita. Science. 2006;312(5775):902–6.

    Article  CAS  PubMed  Google Scholar

  65. Green H, Canfield AE, Hillarby MC, Grant ME, Boot-Handford RP, Freemont AJ, Wallis GA. The ribosomal protein QM is expressed differentially during vertebrate endochondral bone development. J Bone Miner Res. 2000;15(6):1066–75.

    Article  CAS  PubMed  Google Scholar

  66. Sahin F, Qiu W, Wilentz RE, Iacobuzio-Donahue CA, Grosmark A, Su GH. RPL38, FOSL1, and UPP1 are predominantly expressed in the pancreatic ductal epithelium. Pancreas. 2005;30(2):158–67.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  67. Ramagopal S. Induction of cell-specific ribosomal proteins in aggregation-competent nonmorphogenetic Dictyostelium discoideum. Biochem Cell Biol. 1990;68(11):1281–7.

    Article  CAS  PubMed  Google Scholar

  68. Ramagopal S, Ennis HL. Regulation of synthesis of cell-specific ribosomal proteins during differentiation of Dictyostelium discoideum. Proc Natl Acad Sci U S A. 1981;78(5):3083–7.

    Article  CAS  PubMed  PubMed Central  Google Scholar

Download references


We thank Sarah Kubek and Michael Slocum for frog husbandry and Florencia del Viso for her comments on the manuscript. This work was supported by NIH/NHLBI 5R33HL120783 and NIH/NICHD 5R01HD081379 to Mustafa Khokha and NIH R01GM0115710 to Susan Baserga. Mustafa Khokha is a Mallinckrodt Scholar.

Availability of data and materials

All data is available in the manuscript and accompanying supplemental file. Sources of materials used are provided in the materials and methods section.

Authors’ contributions

JG, AR, MKK and SJB conceived the study and designed the experiments. JG, and AR performed the in situ hybridization experiments. NDLO produced the RNA-seq data. JG, MKK and NDLO analyzed the data. JG and NDLO wrote the manuscript. All authors reviewed and approved the final manuscript.

Competing interests

The authors declare that they have no competing interests.

Ethics approval

X. tropicalis were maintained and cared for in our aquatics facility, in accordance with Yale University Institutional Animal Care and Use Committee protocols.

Author information

Authors and Affiliations


Corresponding author

Correspondence to John N. Griffin.

Additional files

Additional file 1:

Corrected rps and rpl gene models with coordinates against the X. tropicalis v7 genome assembly. (PDF 57 kb)

Additional file 2:

Comparison of digoxigenin labeled anti-sense and sense mRNA probes for each ribosomopathy gene in stage 16 embryos. Dorsal and anterior views are shown. Note the strong expression detected in the neural plate by the anti-sense mRNA probes while the control sense probed embryos remains unstained. (JPG 922 kb)

Rights and permissions

Open Access This article is distributed under the terms of the Creative Commons Attribution 4.0 International License (, which permits unrestricted use, distribution, and reproduction in any medium, provided you give appropriate credit to the original author(s) and the source, provide a link to the Creative Commons license, and indicate if changes were made. The Creative Commons Public Domain Dedication waiver ( applies to the data made available in this article, unless otherwise stated.

Reprints and permissions

About this article

Check for updates. Verify currency and authenticity via CrossMark

Cite this article

Robson, A., Owens, N.D.L., Baserga, S.J. et al. Expression of ribosomopathy genes during Xenopus tropicalis embryogenesis. BMC Dev Biol 16, 38 (2016).

Download citation

  • Received:

  • Accepted:

  • Published:

  • DOI:
